Shower Pan Leak Detection & Repair in Tyler, TX
Beneath the tile of a walk-in enclosure sits a hidden waterproof liner, sloped so water finds its weep holes. When that liner cracks or was lapped wrong at the seams, the floor still looks fine while the subfloor below slowly soaks.
Prefer to talk first? Call (903) 651-5125 and describe what you are seeing.
The one layer you never see
A tiled shower floor is not waterproof on its own. Grout and tile shed most of the water, but some always gets through, and the liner below is what catches it and carries it to the drain weep holes. When that liner fails, the tile floor still looks fine while water escapes into the subfloor or the slab below.
That is what makes a pan leak so sneaky. There is no dripping fixture and no obvious crack, just a floor that looks normal and a structure beneath it getting wetter every time someone showers. In newer Briarwood and Brookhaven custom showers, a large tiled pan puts a lot of area on that single liner.
Confirming a pan failure with a flood test
The flood test is how we prove a pan leak. We plug the drain, fill the shower base to a marked level, and watch it over time. A pan that holds is sound. A level that drops, with moisture appearing below or on a ceiling under the shower, confirms the liner has failed.
Thermal imaging and a moisture meter then map where the water has spread into the subfloor or the slab. On a Tyler slab home, that spread matters, because a pan leak can feed moisture into the soil that moves the foundation, so we trace its full reach.
Why the pan repair is the bigger one
Most shower leaks are fixed without disturbing the floor. A pan leak is the exception. Replacing a failed liner means removing the tile floor, taking out the old liner, installing and properly lapping a new waterproof layer, and resetting the tile and drain. It is real work, which is exactly why we confirm the pan is the source first.
We will not tear out a shower floor on a guess. The flood test and the moisture mapping have to point clearly to the pan before we recommend the rebuild, and we price it plainly against the alternative once we know.
Catching a pan leak early
A failing pan gives quiet warnings: a tile or two that loosen, grout that stays damp long after a shower, a musty corner, or a faint stain on the ceiling below. Those are the moments to test, while the damage is still contained to the liner rather than the framing around it.
Left to run, a pan leak rots the subfloor and the wall plates at the base of the shower, turning a liner job into a structural one. The flood test that catches it early is cheap by comparison.
Old and new showers fail differently
An older mud-set shower pan in a mid-century Tyler home fails as the liner ages and cracks. A newer custom build fails more often at the seams and the drain connection, where the waterproofing was lapped or bonded during construction. We read which kind of shower we are dealing with before testing, because the likely failure point changes with the build.
Loose tiles and a damp shower floor?
Talk it through with a licensed Tyler leak specialist, any hour.
☎ (903) 651-5125Questions Tyler homeowners ask
How is a shower pan leak different from a regular shower leak?
A general shower leak can be the valve, the grout, or the door. A pan leak is specifically the hidden liner under the tile floor failing, which lets water into the structure and usually means replacing that floor.
How do you prove it is the pan and not something else?
A flood test. We plug the drain and fill the base, and if the level drops or moisture appears below, the liner has failed. That test is what separates a pan job from a simpler grout or valve fix.
Do you really have to remove the tile floor?
To replace a failed liner, yes, because the waterproofing sits under the tile. That is why we confirm the pan is the source first rather than tearing out a floor on a guess.
Can a shower pan leak affect my slab foundation?
On a slab home it can. Water from a failed pan feeds moisture into the slab and the soil beneath, adding to the movement that already troubles Tyler foundations. We map how far it spread.
What are the early warning signs?
Loose floor tiles, grout that stays wet, a musty corner, or a faint ceiling stain below the shower. Call (903) 651-5125 at the first of these, while it is still just the liner.
